Black IP20 1500m 90Ra 30W LED Track Light With DIP Switch Driver

Shenzhen Coreshine Optoelectronics Co.,Ltd
Contact Now
    Buy cheap Black IP20 1500m 90Ra 30W LED Track Light With DIP Switch Driver from wholesalers

    Buy cheap Black IP20 1500m 90Ra 30W LED Track Light With DIP Switch Driver from wholesalers
    • Buy cheap Black IP20 1500m 90Ra 30W LED Track Light With DIP Switch Driver from wholesalers

    Black IP20 1500m 90Ra 30W LED Track Light With DIP Switch Driver

    Ask Lasest Price
    Brand Name : CoreShine
    Model Number : CTL-1550-X1X2-X3WH
    Certification : CE/CB/ETL/DTC/SAA/FCC/GS/UL
    Price : Negotiable
    Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Supply Ability : 25000-30000 pcs/month
    Delivery Time : 5-8 working days
    • Product Details
    • Company Profile

    Black IP20 1500m 90Ra 30W LED Track Light With DIP Switch Driver

    Black IP20 1500m 90Ra 30W LED Track Light With DIP Switch Driver


    Black Track Panel Light with DIP Switch Driver 1500mm 30W for Retail Store


    Black Track Panel Light with DIP Switch Driver 1500mm 30W for Retail Store


    High End Led Linear Track Light System for Europe Market 1500mm 50W


    ​​DESCRIPTION

    CoreShine T-LINE T-line track linear is a custom design with perfectly matched to Europe 4 wire and North America 3 wires track rail. This new track linear is a continuous seamless lighting with option in-between to install track spot lights, even as a various lens options according to projects requirements. This new track linear is totally tool-less easy to install saves time, cost and labor.


    • Quick and easy linking system, plugged-in or Hardwired optional.
    • Rated for continuous operation, voltage and constant current driving, good reliability.
    • Easy- install aluminum plate, convenient to maintain, excellent heat dissipation, resistant to rust.
    • Triple colors changing, 3000K/4000K/5000K/6000K, high CRI 90 provides excellent lighting effects.
    • 50,000 hours life with 5 years warranty. ETL listed and Energy Star certified.

    Item:Led Track Linear Light System
    Series:T-LineInput Voltage:AC220-240VAC/100-277VAC
    Length:600mm,1200mm,1500mm,2400mmLight Source:Smd2835 (Everlight/Samsung)
    Trunking:600mm,1000mm,1200mm,1500mm,2000mm,2400mm, 3000mm,4000mmMaterial:Aluminum Alloy + PMMA lens / PC cover
    UGR:<19CRI (Ra>):80
    Beam Angle:60°;90°;120°; Double AsymmetricCCT:3000K/4000K/5000K/6000K
    PF:>0.95THD:<15%
    Switch Type:Motion Sensor SwitchLumen:2128lm-16000lm
    Driver:Flicker driver / Non-flicker driverColor:White, Black
    IP Rating:IP20Light Color:Warm White, White, Cold White
    Efficiency:160lm/w, 180lm/wPower:14W-20W,35W-50W,70W-100W
    Warranty:5 yearsLifespan:50,000 h
    Function:Sensor, Track Spot Light, Emergency Exit LightShipping:DHL/UPS/FEDEX/TNT...
    Applications:Supermarket, Warehouse, Office, Stores, Shops, Commercial and Industrial Projects...
    • Output selectable by DIP switch
    • Constant current LED driver
    • Universal voltage input range
    • Steel casing driver, encapsulated

    TRACK LINEAR

    • ​DETAILS
      • Phase pre-selection via adaptor, track linear can be adjusted by moving right or left
      • For Europe standard 4wires,The maximum current is 10A, allowing 60pcs of 1500mm 35w in one serial row 220VAC power supply
      • For America standard 3wires,The maximum current is 10A, allowing 30pcs of 1500mm 35w in one serial row 100VAC power supply
      • Flexible change of installation position
      • Existing track rail
      • Track rail (4 wires / 3 phases)Track rail (3 wires / 1 phase)

        3 separated switchable circuits

        Adapter track box design ensures easy and intuitive fitting in the 3-phase track

        For North America Standard track spot light, there is only one circuit in the lamp.
        Black IP20 1500m 90Ra 30W LED Track Light With DIP Switch DriverBlack IP20 1500m 90Ra 30W LED Track Light With DIP Switch Driver
    • ADVANTAGES
      • Track Spot light can be installed in between
      • Track Linear can be used to existing track rail

    LUMINAIRE

    • MULTIPLE OPTIONS

    ​1.​Different length with various power is available for Europe standards and North American standards.

    Length
    Power
    L x W x HCRI
    Lumen
    Code No.
    600mm
    14W/16W/18W/20W
    600x60x11mm>80Ra
    2240lm-3200lm
    CTL-06xx-X1X2-X3WH
    600mm14W/16W/18W/20W600x60x11mm>90Ra2128lm-3040lmCTL-06xx-X1X2-X3WH
    1200mm
    35W/40W/45W/50W
    1200x60x11mm>80Ra
    5600lm-8000lm
    CTL-12xx-X1X2-X3WH
    1500mm
    35W/40W/45W/50W
    1493x60x11mm>80Ra
    5600lm-8000lm
    CTL-15xx-X1X2-X3WH
    1500mm35W/40W/45W/50W1493x60x11mm>90Ra5320lm-7600lmCTL-15xx-X1X2-X3WH
    2400mm
    70W/80W/90W/100W
    2400x60x11mm>80Ra
    11200lm-16000lm
    CTL-24xx-X1X2-X3WH

    2.Different diffuser for different distribution

    • Narrow 60° UGR<19
    • Wide 90°
    • Flat 120°
    • Double Asymmetric

    Black IP20 1500m 90Ra 30W LED Track Light With DIP Switch Driver

    • OPTICS

    The high light efficiency of 160lm/Watt makes reduction on energy consumption and additional cost. The LEDs keeps enough margin to make sure the luminaire efficiency reach the best level.​

    Black IP20 1500m 90Ra 30W LED Track Light With DIP Switch Driver

    • APPLICATIONS
    • To be accessorial lights for commercial places, industrial, building hall, hotel, store, shop and so on.
    • Applications include spotlighting in offices, residential applications, museums, galleries, retail environments, cafes etc.
    • 100% of the led light will be tested and keep lighting for 24 hours to test its quality reliability, and we will also test its temperature after 24 hours of lighting
    • Then after it is cool we again test 100% of the lamps to see if it still works well. Each lamp should pass all these QC procedures before shipping to customer.

    Black IP20 1500m 90Ra 30W LED Track Light With DIP Switch Driver

    CUSTOMIZATION


    • Fitting color can be refinished
    • Can be supplied with 3/4 circuit track adaptor
    • Dimmable options also available by special request
    • Customization options are subject to availability and minimum order quantities


    OUR ADVANTAGES


    1.Raw material 100% check before production.

    2.Order must have a first sample and full check before the manufacturing process.
    3.100% check before aging.
    4.24 hours aging with 500 times on off testing.
    5.100% final inspection before packing.


    OUR SERVICES

    1.We will reply to the lead time within 24 hours after receiving the customer's confirmation of each order.
    2.Take photos of the goods during production and send them to customers.
    3.Take pictures of goods after packaging and labeling and send them to customers.
    4.Take photos of goods loading before shipment, and arrange the customs clearance information of goods and send them to the customers.
    5.We will track the logistics information and update it to the customer at any time if the goods are delivered by express.
    6.We will remind the customer to prepare the customs clearance documents for the goods before they arrive at the port.
