4 Foot Modular Linear Light Fixture , Suspended Supermarket
Lighting Design
Low UGR Led Linear Indirect Supermarket Lighting Solutions With
Steel Casing Driver
PRODUCT DESCRIPTION
Coreshine U-LINE LED linear light is exclusively designed for designers and architects with
imagination and personal style. LED linear light adopt premium
stain steel housing, different dimension, and size, indirect
diffuser, easy to install and maintain. 3 types of installations
method: ceiling mounted, suspended, and embedded, and different
customized dimensions are also acceptable, which can meet install
location requirements of different fields and occasions.- Low UGR,<19,create comfortable light environment for school,shops & retail
industry
- Indirect light,only see light,not light source,good for eyes
- High lumens efficiency,150lm/W
- 3-phase pre-selection via moving luminaire male connector to right
or left to installation in rail
- Working on trunking rail enable seamless continuous connection
- Maximum length in a series line about 100meter
- The option of dimming: DALI/1-10V/DIM-SWITCH
- Emergency function available
- Compatible with track spotlight, the emergency exit sign, and
motion sensor
- Have two options of light:1)with 10% upward light 2)100% light
downward
PRODUCT DETAILS
Dimming & Multi-Sensor System
· 3 different dimming system, DALI, 0-10V and DIMswitch
· It does not only have an integrated microwave sensor for movement
detection, but also a daylight sensor.
Trunking Rail
· Trunking rail as standard with 5, 8 or 12-core through-wiring
with 2.5mm²cable for power supply and 1.5mm² cable for dimming
control.
· The maximum current is 16A, allowing 70pcs of 1500mm 45W in one
serial row 220VAC power supply,up to 100 meters.
Emergency Lighting Function
· It can work on normal mains and automatically switch to emergency
supply in the event of a power failure to provide sufficient light
and ensure safe evacuation in emergency situations.
· A wide variety of self contained battery is available, as well as
two independent emergency lighting circuits in the trunking.
135-150lm/W
The high lumens efficiency of 135~150 lm per Watt makes reduction
on energy consumption and additional cost. The LEDs keeps enough
margin to make sure the luminaire efficiency reach the best level.
Uplighting
Directs 10% of the light upward to the ceiling and 90% reflected
onto the floor, with or without uplighting is available
Beam Angle
Unique reflective design, two different reflector face forms two
kinds of reflection angle
Length Options
| North American Standard | European Standard |
| Options | ·1200mm 30W 4000lm / 45W 6000lm / 60W 8000lm ·2400mm 60W 8000lm/ 90W 12000lm/ 120W 16000lm . Flicker/non-flicker driver optional . 0-10V driver optional | . 1500mm 35W 5000lm/ 50W 7000lm/ 70W 10000lm . 2400mm 70W 10000lm / 120W 17000lm . Flicker/non-flicker driver optional . Dali/1-10V/standard driver optional |
| Description | Electrical Characteristics | 0-10V Dimming Driver | 30W/45W/60W Length : 2400MM Constant current LED driver Life time:50,000h 5 years warranty | Electrical Characteristics | Output Selectable Driver | 50W/70W Length : 1500MM Constant current LED driver Life time: 50,000h 5 year warranty |
| Properties | High efficiency >=88% Over voltage protection with automatic restart Overload protection Short-circuit protection with automatic restart Surge voltage: 2.5KV | High efficiency >=90% Over voltage protection with automatic restart Overload protection Short-circuit protection with automatic restart Surge voltage: 2.5KV |
SPECIFICATIONS
| Item: | Led Linear Supermarket Light Trunking System |
| Style: | U-Line | Material: | Aluminum Alloy + PMMA lens / PC cover |
| Length: | 1200mm, 1500mm, 2400mm | Light Source: | Smd2835 (Everlight/Samsung) |
| Trunking: | 600mm, 1200mm, 1500mm, 2400mm, 3000mm | Input Voltage: | AC220-240VAC/100-277VAC |
| UGR: | <19 | CRI (Ra>): | 80/95 |
| Beam Angle: | 60°;120°; Asymmetric; Double Asymmetric | CCT: | 3000K/4000K/5000K/6000K |
| PF: | >0.95 | THD: | <15% |
| Lumen: | 4000lm-16000lm | Dimming: | DALI, 1-10V, DIMswitch |
| Driver: | Coreshine/Rubycon | Color: | White Housing |
| IP Rating: | IP20 | Light Color: | Warm White, White, Cold White |
| Efficiency: | 135lm/w-150lm/w | Power: | 35W,50W,65W,70W,100W,150W... |
| Warranty: | 5 years | Lifespan: | 50000 hours |
| Installation | Chain, Cord, Rod, Surface Mounted | Connector | L/T/X Node Connector can be choose |
| Function | Dimmable (DALI/1-10V), Emergency, Sensor, Track Spot Light |
| Switch Type: | Motion Sensor Switch Optional | Shipping: | DHL/UPS/FEDEX/TNT... |
| Applications: | Office, Supermarket, Warehouse, Stores, Shops, Commercial and
Industrial Projects... |
FEATURES
- Seamless continuous connection
- Special optical design, multiple beam angle, UGR less than 19
- The trunking rail with built-in connection accessories, to connect
the electronic parts and structure
- Three colors of the lamp body, black, white, silver
- Installation methods, ceiling and suspending
- High lumen lighting efficiency up to 160LM/W.
APPLICATIONS
Warehouse / Factory / Workshop
Hotel / Hospital / Supermarket
Conference / Meeting room / Factory / Office
Residential Home / Institution Building
School / College / University
Church / Theater / Sport Area
FAQ
Q:Do you have a factory ?
A:Yes,we are the top professional manufacture for this product.
Q:Do you have patent for this product?
A:Yes,we have patent in appearance design and function design.
Q:What is the maximum power in one line?
A:3500W
Q:Can it be DALI or 1-10V dimming?
A:Yes,it can be DALI dimming or 1-10V dimming or DIM switch.
OUR SERVICES
1.We will reply to the lead time within 24 hours after receiving
the customer's confirmation of each order.
2.Take photos of the goods during production and send them to
customers.
3.Take pictures of goods after packaging and labeling and send them
to customers.
4.Take photos of goods loading before shipment, and arrange the
customs clearance information of goods and send them to the
customers.
5.We will track the logistics information and update it to the
customer at any time if the goods are delivered by express.
6.We will remind the customer to prepare the customs clearance
documents for the goods before they arrive at the port.
ADVANTAGES
1. Quality is our Culture
2. Fast Delivery Time
3. Legal Business Assurance and Trust
4. Professional Customer-care Service
5. Customization is acceptable
6. Cooperate to Develop Your New Products
PICTURES
